Lexmark Optra e260 e360 e460 x264 - Refill Toner Cartridge

Remanufacturing instructions for Lexmark Optra E260d E260dn E360d E362dn E460dn E460dw E462 X264 X363 X264 toner cartridge SUPPLIES NEEDED: -Toner vacuum or compressed air -Screwdriver -Needle nose pliers -Toner for Lexmark E260 -- universal Lexmark toner works without problems -Isopropyl Alcohol -Chip These printers have 2 types of cartridge: standard and "Return" program (Prebate) cartridges. Oem high yield cartridges do not work in e260 series, but only in e360/e460 series. Extra high yield cartridge is only used in Optra e460 series. There is also a 18000 pages EHY cartridge, for use only in Optra e462. Lexmark X264 X363 X364 also use this type of cartridge, with a different chip. The toner cartridge is the same all around the world, but Europe, USA, Latin America and Asia/Pacific have different chip. For example, if you buy a OEM cartridge in Asia, you can't use it in a printer sold in USA or Europe. TONER CARTRIDGES e260/360/460 - EUROPE MIDDLE EAST 0E260A11E Standard Return cartridge 3500 pages 0E260A21E Standard cartridge 3500 pages 0E360H11E High Yeld Return e360 e460 9000 pages 0E360H21E High Yeld Standard e360 e460 9000 pages 0E460X11E Extra HY Return cartridge e460 15000 pages 0E460X21E Extra HY Standard Cartridge e460 15000 pages 0E462U11E Extra HY Return cartridge e462 18000 pages TONER CARTRIDGES e260/360/460 - USA CANADA E260A11A Standard Return cartridge 3500 pages E260A21A Standard cartridge 3500 pages E360H11A HY Return E360/460 9000 pages E360H21A HY Standard E360/460 9000 pages E460X11A EHY Return cartridge E460 15000 pages E462U11A EHY Return cartridge E462 18000 pages TONER CARTRIDGES e260/360/460 - ASIA E260A11P Standard Return cartridge 3500 pages E260A21P Standard cartridge 3500 pages E360H11P High Yeld Return E360/460 9000 pages E360H21P High Yeld Standard E360/460 9000 pages E460X11P EHY Return cartridge E460 15000 pages E460X21P EHY Standard Cartridge E460 15000 pages E462U11P EHY Return cartridge E462 18000 pages TONER CARTRIDGES e260/360/460 - LATIN AMERICA E260A11L Standard Return cartridge 3500 pages E260A21L Standard cartridge 3500 pages E360H11L HY Return E360/460 9000 pages E360H21L HY Standard E360/460 9000 pages E460X11L EHY Return cartridge E460 15000 pages E460X21L EHY Standard Cartridge E460 15000 pages E462U11L EHY Return cartridge E462 18000 pages TONER CARTRIDGES X264/X363/X264: - LATIN AMERICA X264A11L Standard Return cartridge 3500 pages X264H11L HY Return cartridge 9000 pages • 363 • 364 MFP TONER - ASIA X264A11P Standard Return cartridge 3500 pages X264H11P HY Return cartridge 9000 pages - USA CANADA X264A11G Standard Return cartridge 3500 pages X264H11G HY Return cartridge 9000 pages - EUROPE MIDDLE EAST X264A11E Standard Return cartridge 3500 pages X264H11E HY Return cartridge 9000 pages How to print a test page (e360 e460 X363 X364): 1. Press "Key" button on the control panel 2. Press "Down Arrow" button until UTILITIES MENU appears on the display of the printer 3. Press "Select" button 4. Press "Down Arrow" button until PRINT MENUS, PRINT STATS, or PRINT FONTS appears on the display. REPETITIVE DEFECTS 98.3 mm: Drum (drum unit) 38.8 mm: Charge roller (drum unit) 48.3 mm: Developer Roller(cartridge) 52.4 mm: Transfer Roller (printer) 80.0 mm: Upper fuser Belt (printer) PRINTER ERROR CODES - 30.XX Cartridge Error: problem with the chip or mechanical issue in the toner cartridge. - 31.XX Defective Cartridge Error: problem with the toner cartridge chip, problem with the chip reader in the printer, cartridge missing. - 200.XX: paper jam. - 920.XX, 921.XX, 922.XX: fuser unit errors. -------------------------------------------- Link Accessori srl Via Beverara 224/7 40131 BOLOGNA (Italy) email: link.accessori@libero.it http://www.linkaccessori.it/ other links: http://www.emmegiricambi.it/ http://www1.lexmark.com/it_IT/ -------------------------------------------------------------------------
