TIG/GTAW TIG200P HF-TIG/ Pulsing Tig
Yamatec TIG 200P DC Inverter Digital Welding Machine Technical Specifications: Rated input power supply Single phase AC220V+-15% Input frequency (Hz) 50/60 Input frequency (Hz) 50/60 Rated input peak current (A) 16 Rated Power capacity (KVA) 6 Rated output current (A/V) MMA 160/26.4 TIG 200/18 Output current range (A) MMA 10~160 TIG 5~200 No load voltage (V) 56 Pre-flow time (S) 0.5 Post-flow time (S) 0.5-20 Pulse frequency (Hz) 1~200 Arc start High Frequency Efficiency (%) 85 Duty circle (%) 160A(ARC)-30%200A(TIG)-25% Power factor 0.7 Insulation grade B Enclosure protection class IP21S Weight (Kg) 9 Size (mm) 502*217*381
