Tachometer S1/2 - Testing and Calibration

Step by Step procedure to: - Test a Tacho S1/2 board - Calibrate a Tacho S1/2 board We test/calibrate: 00:00 Introduction 01:51 Green backlight, Yellow LEDs 04:17 Dummy displays 05:10 Voltmeter 08:23 Engine Coolant Temperature 14:02 Oil Pressure 17:30 Engine RPM Rotations per Minute Download pdf CheatSheet for calibration here: http://www.ideegeniali.it/shop/attachment.php?id_attachment=125
