Phat PS4 HDMI Pin-out - SAA-001 / SAB-001 Motherboard (10xx / 11xx Series)

This video shows the HDMI output circuit for the PS4 games console (CECH-100XX and CECH-11XX models). It describes what to do in the event that you destroy any pads connecting the port to the motherboard when replacing a HDMI port on the console, and at the end shows diagrams where you can run link wires to rebuild the destroyed circuits.
