Craig Hollabaugh: 160125 Faraday Coil Winder - Introduction
Faraday is an open-source coil winder to learn about transformer design for audio tube amplifiers. This winder builds on bits and pieces from other designs while being accurate and inexpensive to build. Using open-source software FreeCAD, GRBL and ChiliPeppr. project page https://github.com/holla2040/faraday lead screw http://www.aliexpress.com/item/2pcs-T... B12 drill chuck for NEMA 17 5mm shaft http://www.ebay.com/itm/Mini-Electric... GRBL https://github.com/grbl/grbl ChiliPeppr http://chilipeppr.com/ How It's Made, McIntosh Output Transformers https://youtu.be/2HgS6gvokEI?t=1m59s
