CANON ColorStream 6000 series LIVE DEMO
Specifications in detail Technology Print Technology DigiDot® drop-on-demand, piezoelectric Ink Water based dye, pigment, premium pigment, Chromera ink Drop Size Variable, 5 - 12 picoliter Paper transport Pinless, tight web, automatic tension control Paper input tight web unwinder (included in basic unit), optional stack infeed* *Max. print speed with optional stack infeed 75 m/min or 505 A4/min Paper output Open post-processing interface with Type1 connectivity, Optional Rewinder or stack outfeed Paper Print width 6.5"-21.25" (165-540 mm) Page length 3"-60" (76-1520 mm) Paper width 6.5"-22" (165-560 mm), optional stack infeed 6,5" bis 19,5" (165-495 mm) Form length internal stacker: 7"-14" (178-356 mm), stack height max. 300 mm Paper Weight 60-160 gr/m², optional stack infeed 64-120 gr/m²* *Depending on the type of ink and given that paper test results are positive, the paper range can be extended to 40 – 235 gsm Substrates Preprinted, inkjet, laser and recycled newspaper Reel shafts 70 mm, 3", 5" and 6" Physical data Length x Width (Single) 7,460 mm × 1,400 mm*** ***Roll-to-roll configuration including unwinder and rewinder Length x Width (Inline Twin) 11,950 mm × 1,400 mm*** ***Roll-to-roll configuration including unwinder and rewinder Length x Width (L-Twin) 7,700 mm × 7,000 mm*** ***Roll-to-roll configuration including unwinder and rewinder Length x Width (H-Twin) 8,000 mm × 5,100 mm*** ***Roll-to-roll configuration including unwinder and rewinder Height 1,950 mm Weight (Single) 2,500 kg Weight (Twin) 5,300 kg Power connection requirements Connection (EU) 400 V, 63 A Environmental Temperature Optimal range 20-26 °C Humidity Optimal range 40-60% Operating noise Maximum 75 dB Workflow Controller SRA MP high-performance blade processors Printer data format (AFP / IPDS (IS/3), PDF (APPE), Line Data, LCDS, PostScript, PPML, TIFF, VIPP)** **Partly in combination with PRISMAproduction Print manager (optional) PRISMAproduction® Connectivity Gigabit Ethernet (copper); 10 Gigabit Ethernet (copper, Optic MMF/SR, Optic SMF/LR) Disclaimer All information is subject to change without notice. MODEL 6200 6500 (Chroma) 6700 (Chroma) 6900 (Chroma) Print resolution CYMK 600 x 600 dpi* 600 x 600 dpi at 100m/min* 600 x 480 dpi at 127 m/min* Print resolution fast-monochrome 600 x 600 dpi* Print speed CMYK A4 pages per minute (Single/Twin) 324 / 648 505 / 1,010 675 / 1,350 857 / 1,714 Print speed fast-monochrome A4/min (Single/Twin) 1,010 / 2,020 Duty cycle CMYK million A4 per month (Single/Twin) 2 - 20 / 5-21 4 - 16 / 7 - 33 5 - 22 / 10 - 44 6 - 28 / 12 - 56 Duty cycle fast-monochrome million A4 per month (Single/Twin) 7 - 32 / 14 - 65 Power consumption (EU) (Single /Twin) 20 kW / 32 kW 21 kW / 34 kW 23 kW / 38 kW 25 kW / 43 kW Consumption idle (EU) (Single/Twin) 4 kW / 5 kW
